W |
Vdc |
A |
rpm |
W |
Vdc |
A |
rpm |
MINI-H100 |
46 |
20 |
2.22 |
6750 |
90 |
24 |
3.8 |
8300 |
MINI-H200 |
82 |
19 |
4.3 |
7166 |
230 |
24 |
9.8 |
8500 |
MINI-H300 |
190 |
19 |
10 |
7800 |
550 |
24 |
16.5 |
9000 |
MINI-H400 |
320 |
19 |
17.5 |
7100 |
900 |
24 |
35 |
9000 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
LPM |
kPa |
LPM |
kPa |
Kg |
LPM |
kPa |
dB(A) |
Kg |
MINI-H100 |
130 |
5 |
300 |
8 |
1.1 |
260 |
8 |
53 |
1.8 |
MINI-H200 |
260 |
5 |
500 |
14 |
1.6 |
450 |
14 |
56 |
2.8 |
MINI-H300 |
400 |
8 |
850 |
19 |
2.5 |
650 |
16 |
61 |
4.1 |
MINI-H400 |
600 |
10 |
1050 |
24 |
4.1 |
950 |
22 |
62 |
6.2 |
|
|
|
|
상기 특성은 주입온도 15℃, 대기압 1013mbar 기준으로 측정한 결과이며 허용 오차는 ±10%임. |
|
|
|
|
|
|
ELECTRICAL DATA |
RATED VOLTAGE |
24 VDC |
MAX OUTPUT CURRENT |
30 A |
OPERATING TEMPERATURE |
-20℃~ 105℃ |
MOTOR DRIVE FREQUENCY |
22.5 KHz |
SPEED CONTROL VOLTAGE |
0 ~ 10 VDC |
|
|
|
-Temperature : Working Air 0℃ to 40℃, Ambient Air 0℃ to 40℃.
- RPM can be controlled by the input voltage.
- When the blower is used for vacuuming, there is an approximate reduction of 5% in the performance.
- Hard Mounting cvan be made by clamping around the motor's AL casing.
- 2-wire power connection. (Yellow : (+) DC, Black : (-) DC), Improper connection will damage the blower. |
